Gantry Multi Disc Block Cutting Machine with Turning Worktable

Gantry Multi Disc Block Cutting Machine with Turning Worktable

LMQ2200/2500 Gantry block cutting machine The elevation of blade is driven by crossbeam to increase the cutting flatness;
Send inquiry
Basic Info
Model NO. LMQ2200
Control Artificial
Certification ISO, CE
Transport Package Bubble Bag
Specification 6600x6000x4800mm
Trademark wanlong
Origin Quanzhou
HS Code 8464101000
Production Capacity 35sets/Month
Product Description
LMQ2200/2500 Gantry block cutting machine

The elevation of blade is driven by crossbeam to increase the cutting flatness and processing scope Sliding speed of blade on the crossbeam is adjustable

SPECIFICATIONS FOR QSQ
Model LMQ-2200LMQ2500
Max.diameter of blademm22002500 (3000 optinal)
Max.No.of bladespc31
Recommended Blade Combination mmØ2200,Ø1600,Ø940Ø2500
Main motor powerKw3030
Max.Cutting Sizemm3000*2000*9503000*2000*1000
Overall Dimension mm6600*6000*48006600*6000*4800
Water consumptionm³/h1010
Approximate weight kg90009000
