Gantry Multi or Single Disc Block Cutting Machine with Turning Worktable

Basic Info

Type	Gantry Cutting Machine
Usage	Ceramics, Glass, Fire Brick, Red Brick, Jadestone, Cement Brick, Concrete Curb, Granite, Marble, Limestone, Basalt, Sandstone
Application	Machinery & Hardware, Construction, Stone Industry
Source Voltage	380V
Automation	Automatic
Cutting Ability	High Speed
Control	Automatic
Certification	API, ISO, CE, SGS
Main Motor	30
Max PCS of Blade	1-3PCS
PLC Brand	Panasonic
Main Motor Brand	Siemens
Working Table with Encoder	Optional
Max. Cutting Size	3000*2000*1100
Program	Computerized by Panasonic PLC
Transport Package	Water-Proof Plastic Bubble Wrapping and Steel Wire
Specification	6600*6000*4800mm
Trademark	Wanlong
Origin	Quanzhou City, China
HS Code	8464101000
Production Capacity	100sets Per Month

Product Description

Low Cost Gantry Type Cutting Machine (LMQ-2200)
Technical parameters LMQ-2200Max blade diameter: Mm ø 2200Max cutting length: 3000Max cutting width: 2000Max cutting height: 1100Main motor power: 30kwWater consumption: 6M³ /h Overall dismension: 6000*4700*6000mmApproximate weight: Kg 9000

		LMQ-2200	LMQ-2500	LMQ-3000
Max. diameter of blade	mm	2200	2500	3000
Max. No. of blades	pc	3	1	1
Recommended Blade Combination	mm	2200 1600 940	2500	3000
Recommend saw blade thickness	mm	6.5	8	8.0
Main motor power	KW	30	30	37
Table dimensions ( L x W )	mm	2000*2000	2000*2000	2000*2000
Max. cutting size (L x W x H)	mm	3200*2000*950	3000*2000*1100	2500*2000*1350
Overall dimensions ( L x W x H )	mm	6600*600*4800	6600*6000*4800	7000*4700*6000
Water consumption	m3/h	6	6	6
Approximate weight	Kg	9000	9000	9000

Packaging & Shipping
DELIVERY TIME:

35-45days as per produciton schedule and quanity.
if your order is in our stock, we can effect shipment once received your payment

PACKAGE:
Suitable for seaworthy container shipment

WARRANTY:
12 MONTHS

SHIPMENT WAY:
-by sea: can be Less than Container Load and Full Container Load; freight is according to the shiping company quoation to your seaport.
-you can consult us when you make inquiry.

Our Services
Service:
- fast deliver time: 7- 15 days.
to rough idea: most of order lead time is 7 days-10days.
-consistent quality control:
Raw material: have advanced device for diamond, powder ete inspection;
Production: production procedure been strictly controlled by quality controlled department;
Finshed product: All produced product has been inspetion and approved before shipment.
-any quality related problem that we are care and will solved for client.
